Specification

Model 8AS
Flow Rates Up to 8000 LPH
Output/Regeneration(m3) Based on feed water hardness 200PPM CaCO3 50
Purple Resin Quantity(liter) Zr NaF 200
Coarse Silex (Kg) 20
Cabinet Salt Capacity in kgs Maximum 200
Salt Per Recharge in kgs 30
Brine Volume (Liter) 100
Brine Float Setting (mm) 420
Process Valve Fully Automatic Programmable
Softener Vessel & Brine Tank FRP composite vessel tank & HDPE brine tank
Vessel Size 21" dia. x 62" Height, 4" Top Opening
Regeneration Pump Centrifugal mono block pump
Installation Footprint 6 x 6 sq. ft.
Electric Supply Requirements 230VAC, 6Amp = 2 Points
