Specification

Water Flow 6000 L/ 1.5hr
Dimension (D*W*H) Area occupied 4 X 5 ft
Inlet Water Pressure 1.5 to 3.5 kg/cm2
Inlet Max Hardness (As Caco3) 800 ppm
Treated Water Hardness (As Caco3) <50 ppm
Inlet/ Outlet Connection Size 1 inch
Drain line 0.5 inch
Electric Supply 230 V AC/6 amp = 2 points Electric
Treated Water output at 500 ppm 9000 liters
Salt Capacity 200 kg
Regeneration Pump Self priming pump (with inbuilt NRV)
Installation Footprint Area Occupied 4 x 5 ft.
Purple Resin Quantity 90 liters
Softener Vessels Composite Filament Wound Resin Vessel and HDPE Brine Tank
Process Valve Fully Automatic Programmable
Salt per recharge in kgs 14
